DOONARCES 1200W 48V Electric Outboard Motor Heavy Duty Trolling Engine Motor for Fishing Boat Inflatable/Iron/Plastic/Fiberglass Boats Short Shaft Brushless Motor, Black (48V 1200W)

Description

• Powerful Brushless MotorThe electric outboard motor is equipped with a pure copper brushless motor with maximum power of 1200w, voltage 48V, rated speed: 3000rpm, no-load speed: 4000rpm; Powerful power makes its maximum speed up to 5-8km/h
• Energy Saving&Low NoiseElectric driven outboard is more energy saving, less pollution and less noise. In addition, brushless motors do not need to replace carbon brushes, more efficient than brushed motors, more convenient maintenance, power and time saving
• DurableThe electric brushless outboard motor is made of high quality aluminum alloy, with a solid structure and a load capacity of 1102lbs. Its surface is superbly painted to improve wear resistance and durability, and is suitable for both fresh and salt water environments, with a long service life
• Flexible ControlThe heavy-duty fishing boat electric outboard motor has stepless variable speed and reverse gear, positive gear constant speed function; three-blade propeller can effectively prevent winding, reduce underwater resistance and improve propulsion efficiency; the bracket can be rotated 180, the joystick can be rotated 360 omnidirectional, flexible and convenient operation, giving you a better sea driving experience
• ApplicationThe electric outboard motor is widely used in fishing, marine sports, etc. It is suitable for vessels less than 5m/16.4ft in length: such as inflatable boats, fiberglass boats, wooden boats, iron boats, plastic boats, etc.

Detail
Key Switch: You can turn the key to control the opening, closing, and stopping of the outboard engine.
Ergonomic Handle: Comfortable to hold. The gear buttons at the handle make it easy to operate.
Heat Dissipation Holes: Multiple heat dissipation holes can help the motor dissipate heat.

Specification
Model: DD-48V-1200W
Power: 1200W
Rated Voltage: 48V
Rated Current: 25A
Rated Speed: 3000rpm
No-load Speed: 4000 rpm
Process: Spray Painting
Gear Ratio: 2.08(27:13)
Control System: Tiller Control
Thrust: 3000lbs
Max. Speed: 5-8km/h (according to the environment, waters, the boat load different speed will be different)
Motor Type: Pure Copper Brushless Motor
Reverse Gear: Yes
Max. Load-bearing Capacity: 500kg/1102lbs
Recommended Battery: 1*48V/4*12V (Not Included ) (capacity of 40Ah can be used for about 2 hours, the longer the duration of the time the slower speed)
Propeller Model(in): 7-1/4x5-A(The size of the propeller is 7.25 inches/18.4cm, and the propelling distance of the propeller is 5 inches/12.7cm after one revolution)
Length of Suitable Ships: Less than 5m/16.4ft
Package Size: 95*42*29cm/37.4*16.53*11.41in
Product Size: 92*36.5*22cm/36.22*14.37*8.66in
Gross Weight: 14kg/30.86lbs
Net Weight: 12kg/26.45lbs
Tail Plate Height: 42cm/16.53in(Short Shaft)
Stern Plate Adapter Height: 40cm/15.74in
EPA: PSDOS.0565GA-006
EO:Q-09-001

Package Included
1* Electric Outboard Motor
1* Propeller
1*User Manual
2*Keys

NOTE
1. Our machines are all without gear oil versions, please prepare it by yourself. Please add gear oil to the gears before using the motor and replace gear oil after the run-in period.
